Build Debian live CD and USB with live-build

Galleria:
Debian build live CD Logo
Inglese

Build Debian live CD or a live USB with live-build, we would go trough tree steps, create a git to track all the modify in the code, install live-build in our Debian distribution, configure and build the .iso file.


Create git repository


We can use an online one, can be done online from the official site of GitLab

Create a new project in this example "Fabian-os", and a quick Readme.md for the project home

Is necessary to add the ssh public keys to the project, to be able to have full access to the repository, this could be done in the settings


Clone the repository, it's possible to find the clone button in the home with the two options, HTTPS or SSH

In this case we can use SSH, to be able to push commits with the new code



$ git clone [email protected]:undj/fabian-os.git


The repository directory will be where we will work and store all the configuration of live-build

Since our git don't need to include all the files downloaded by live-build, we should exclude them, we can use the .gitignore provided in our repo


Install live-build


The live-build package can be found and installed directly from Debian repository, in all the trees, from Debian stable to sid

Install live-build with:


$ sudo apt install live-build


live-build use


Live build package provide the executable lb, used to create the environment, build live distribution and for the cleanup


Configure the environment with lb config


We configure the environment, of our live CD, using lb config inside the git directory:



$ sudo lb config


This command will download and create configuration files necessary for build the distribution

We can to add and push the files to git in order to keep track of the first default configuration



$ git add .
$ git commit -m "first configuration"
$ git push


Configuration files


The main configuration is auto/config



$ cat auto/config

#!/bin/sh
set -e
lb config noauto \
    --mode debian \
    --architectures amd64 \
    --debian-installer live \
    --archive-areas "main contrib non-free" \
    --apt-indices false \
    --memtest none \
    -d buster \
    --compression lzip \
    --system live \
    --backports true \
    --bootappend-live "boot=live components locales=it_IT.UTF-8 keyboard-layouts=it splash" \
    --mirror-bootstrap http://deb.debian.org/debian/ \
    --mirror-binary http://deb.debian.org/debian/ \
    "${@}"


Let's see the definition in the script



-d|--distribution CODENAME
    defines the distribution of the resulting live system
--compression bzip2|gzip|lzip|none
    defines the compression program to be used to compress tarballs.
--mode debian|progress|ubuntu
    defines a global mode to load project specific defaults.
-a|--architectures ARCHITECTURE
    defines the architecture of the to be build image.
--archive-areas ARCHIVE_AREA|"ARCHIVE_AREAS"
    defines which package archive areas of a debian packages archive should be used for configured debian package mirrors.
--system live|normal
    defines if the resulting system image should a live system or a normal, non-live system.


The full manual can be found on lb config Debian man pages


We can add some packages, creating a list on the package-list directory



$ nano config/package-lists/


Execute script in the live CD chroot adding them in this directory



$ nano config/hooks/live/my-chroot-script.sh


Is possible to include files in the chroot, using the same directory tree as the one desired in the live CD, adding them in this directory:



config/includes.chroot


Build Debian live CD with lb build


We can now build the live CD with live build, this will download all the packages from the mirror and create the .iso file of the distribution



$ sudo lb build


After the completion of the process or for build a new version, we need to cleanup the environment from previous build



$ sudo lb clean


Final credits


This work has been done in collaboration with the Cagliari's Fablab, to create the custom distribution Fabian, many thanks for the opportunity!
